102 Fixed Cycles: Drilling

3.11 Programming Examples

6 L X+10 Y+10 R0 FMAX M3

Approach hole 1, spindle ON

7 CYCL CALL

Cycle call

8 L Y+90 R0 FMAX M99

Approach hole 2, call cycle

9 L X+90 R0 FMAX M99

Approach hole 3, call cycle

10 L Y+10 R0 FMAX M99

Approach hole 4, call cycle

11 L Z+250 R0 FMAX M2

Retract in the tool axis, end program

12 END PGM C200 MM
