HEIDENHAIN iTNC 530 57

2.2 Program Defaults for Cycles

Global data for probing functions

U Setup clearance: Distance between stylus and workpiece surface

for automated approach of the probing position

U Clearance height: The coordinate in the touch probe axis to which

the TNC traverses the touch probe between measuring points, if the

Move to clearance height option is activated

U Move to clearance height: Select whether the TNC moves the

touch probe to the setup clearance or clearance height between the

measuring points

Applies to all Touch Probe Cycles 4xx.
