HEIDENHAIN iTNC 530 505
19.6 Measuring Tool Length and Radius (Cycle 33 or 483, ISO: G483)
19.6 Measuring Tool Length and
Radius (Cycle 33 or 483, ISO:
G483)
Cycle run
To measure both the length and radius of a tool, program the
measuring cycle TCH PROBE 33 or TCH PROBE 482 (see also
”Differences between Cycles 31 to 33 and Cycles 481 to 483” on
page 495). This cycle is particularly suitable for the first measurement
of tools, as it saves time when compared with individual
measurement of length and radius. In input parameters you can select
the desired type of measurement:
Measuring the tool while it is rotating.
Measuring the tool while it is rotating and subsequently measuring
the individual teeth.
The TNC measures the tool in a fixed programmed sequence. First it
measures the tool radius, then the tool length. The sequence of
measurement is the same as for measuring cycles 31 and 32.
Please note while programming:
Before measuring a tool for the first time, enter the
following data on the tool into the tool table TOOL.T: the
approximate radius, the approximate length, the number
of teeth, and the cutting direction.
Cylindrical tools with diamond surfaces can be measured
with stationary spindle. To do so, define the number of
teeth (CUT) with 0 and adjust the machine parameter
6500. Refer to your machine tool manual.
You can run an individual tooth measurement of tools with
up to 99 teeth. The TNC shows the measured values of up
to 24 teeth in the status display.
