HEIDENHAIN iTNC 530 255
10.2 RUN 3-D DATA (Cycle 30, DIN/ISO: G60)
10.2 RUN 3-D DATA (Cycle 30,
DIN/ISO: G60)
Cycle run
1 From the current position, the TNC positions the tool at rapid
traverse FMAX in the tool axis to the setup clearance above the MAX
point that you have programmed in the cycle.
2 The tool then moves at FMAX in the working plane to the MIN point
you have programmed in the cycle.
3 From this point, the tool advances to the first contour point at the
feed rate for plunging.
4 The TNC subsequently processes all points that are stored in the
digitizing data file at the feed rate for milling. If necessary, the
TNC retracts the tool between machining operations to the setup
clearance if specific areas are to be left unmachined.
5 At the end of the cycle, the tool is retracted at FMAX to the setup
clearance.
Please note while programming:
You can particularly use Cycle 30 to run conversational
programs created offline in multiple infeeds.
