HEIDENHAIN iTNC 530 509
Overview
Overview
Fixed cycles
Cycle
number
Cycle designation
DEF
active
CALL
active
Page
7 Datum shift îš„ Page 274
8 Mirror image îš„ Page 282
9 Dwell time îš„ Page 303
10 Rotation îš„ Page 284
11 Scaling factor îš„ Page 286
12 Program call îš„ Page 304
13 Oriented spindle stop îš„ Page 306
14 Contour definition îš„ Page 185
19 Tilting the working plane îš„ Page 290
20 SL II contour data îš„ Page 190
21 SL II pilot drilling îš„ Page 192
22 SL II rough out îš„ Page 194
23 Floor finishing SL II îš„ Page 198
24 Side finishing SL II îš„ Page 199
25 Contour train îš„ Page 201
26 Axis-specific scaling îš„ Page 288
27 Cylinder surface îš„ Page 221
28 Cylindrical surface slot îš„ Page 224
29 Cylinder surface ridge îš„ Page 227
30 Run 3-D data îš„ Page 255
32 Tolerance îš„ Page 307
39 Cylinder surface external contour îš„ Page 230
200 Drilling îš„ Page 75
201 Reaming îš„ Page 77
202 Boring îš„ Page 79
203 Universal drilling îš„ Page 83
