HEIDENHAIN iTNC 530 137
4.11 Programming Examples
Q204=0 ;2ND SETUP CLEARANCE 0 must be entered here, effective as defined in point table
Q211=0.2 ;DWELL TIME AT DEPTH
10 CYCL CALL PAT F5000 M3 Cycle call in connection with point table TAB1.PNT
Feed rate between points: 5000 mm/min
11 L Z+100 R0 FMAX M6 Retract the tool, change the tool
12 TOOL CALL 2 Z S5000 Call tool: drill
13 L Z+10 R0 F5000 Move tool to clearance height (enter a value for F)
14 CYCL DEF 200 DRILLING Cycle definition: drilling
Q200=2 ;SETUP CLEARANCE
Q201=-25 ;DEPTH
Q206=150 ;FEED RATE FOR PECKING
Q202=5 ;PLUNGING DEPTH
Q210=0 ;DWELL TIME AT TOP
Q203=+0 ;SURFACE COORDINATE 0 must be entered here, effective as defined in point table
Q204=0 ;2ND SETUP CLEARANCE 0 must be entered here, effective as defined in point table
Q211=0.2 ;DWELL TIME AT DEPTH
15 CYCL CALL PAT F5000 M3 Cycle call in connection with point table TAB1.PNT
16 L Z+100 R0 FMAX M6 Retract the tool, change the tool
17 TOOL CALL 3 Z S200 Tool call for tap
18 L Z+50 R0 FMAX Move tool to clearance height
19 CYCL DEF 206 TAPPING NEW Cycle definition for tapping
Q200=2 ;SETUP CLEARANCE
Q201=-25 ;DEPTH OF THREAD
Q206=150 ;FEED RATE FOR PECKING
Q211=0 ;DWELL TIME AT DEPTH
Q203=+0 ;SURFACE COORDINATE 0 must be entered here, effective as defined in point table
Q204=0 ;2ND SETUP CLEARANCE 0 must be entered here, effective as defined in point table
20 CYCL CALL PAT F5000 M3 Cycle call in connection with point table TAB1.PNT
21 L Z+100 R0 FMAX M2 Retract in the tool axis, end program
22 END PGM 1 MM
