140 Fixed Cycles: Pocket Milling / Stud Milling / Slot Milling
5.1 Basics
5.1 Basics
Overview
The TNC offers 6 cycles for machining pockets, studs and slots:
Cycle Soft key Page
251 RECTANGULAR POCKET
Roughing/finishing cycle with selection
of machining operation and helical
plunging
Page 141
252 CIRCULAR POCKET
Roughing/finishing cycle with selection
of machining operation and helical
plunging
Page 146
253 SLOT MILLING
Roughing/finishing cycle with selection
of machining operation and reciprocal
plunging
Page 150
254 CIRCULAR SLOT
Roughing/finishing cycle with selection
of machining operation and reciprocal
plunging
Page 155
256 RECTANGULAR STUD
Roughing/finishing cycle with stepover, if
multiple passes are required
Page 160
257 CIRCULAR STUD
Roughing/finishing cycle with stepover, if
multiple passes are required
Page 164
