HEIDENHAIN ITNC 530 - CYCLE PROGRAMMING User Manual

HEIDENHAIN iTNC 530 223
8.2 CYLINDER SURFACE (Cycle 27, DIN/ISO: G127, Software Option 1)
Cycle parameters
U Milling depth Q1 (incremental): Distance between
the cylindrical surface and the floor of the contour.
Input range: -99999.9999 to 99999.9999
U Finishing allowance for side Q3 (incremental):
Finishing allowance in the plane of the unrolled
cylindrical surface. This allowance is effective in
the direction of the radius compensation. Input
range -99999.9999 to 99999.9999
U Setup clearance Q6 (incremental): Distance between
the tool tip and the cylinder surface. Input range 0 to
99999.9999, alternatively PREDEF
U Plunging depth Q10 (incremental): Infeed per cut.
Input range: -99999.9999 to 99999.9999
U Feed rate for plunging Q11: Traversing speed of the
tool in the spindle axis. Input range 0 to 99999.9999,
alternatively FAUTO, FU, FZ
U Feed rate for milling Q12: Traversing speed of the
tool in the working plane. Input range 0 to
99999.9999, alternatively FAUTO, FU, FZ
U Cylinder radius Q16: Radius of the cylinder on which
the contour is to be machined. Input range 0 to
99999.9999
U Dimension type? ang./lin. Q17: The dimensions for
the rotary axis of the subprogram are given either in
degrees (0) or in mm/inches (1).
Example: NC blocks
63 CYCL DEF 27 CYLINDER SURFACE
Q1=-8 ;MILLING DEPTH
Q3=+0 ;ALLOWANCE FOR SIDE
Q6=+0 ;SETUP CLEARANCE
Q10=+3 ;PLUNGING DEPTH
Q11=100 ;FEED RATE FOR PLNGNG
Q12=350 ;FEED RATE FOR MILLING
Q16=25 ;RADIUS
Q17=0 ;TYPE OF DIMENSION
