236 Fixed Cycles: Cylindrical Surface

8.6 Programming Examples

8 L C+0 R0 FMAX M3 M99

Pre-position rotary table, spindle ON, call the cycle

9 L Z+250 R0 FMAX

Retract the tool

10 PLANE RESET TURN FMAX

Tilt back, cancel the PLANE function

11 M2

End of program

12 LBL 1

Contour subprogram, description of the midpoint path

13 L C+40 X+0 RL

Data for the rotary axis are entered in mm (Q17=1), traverse in the X

axis because of 90° tilting

14LX+35

15 L C+60 X+52.5

16LX+70

17 LBL 0

18 END PGM C28 MM
