11.3 DATUM Shift with Datum Tables (Cycle 7, DIN/ISO: G53)
Please note while programming:
Danger of collision!
Datums from a datum table are always and exclusively
referenced to the current datum (preset).
MP7475, which earlier defined whether datums are
referenced to the machine datum or the workpiece datum,
now serves only as a safety measure. If MP7475 = 1, the
TNC outputs an error message if a datum shift is called
from a datum table.
Datum tables from the TNC 4xx whose coordinates are
referenced to the machine datum (MP7475 = 1) cannot be
used in the iTNC 530.
If you are using datum shifts with datum tables, then use
the SEL TABLE function to activate the desired datum table
from the NC program.
If you work without SEL TABLE, then you must activate the
desired datum table before the test run or the program
run. (This applies also to the programming graphics).
îš„ Use the file management to select the desired table for
a test run in the Test Run operating mode: The table
receives the status S.
îš„ Use the file management in a program run mode to
select the desired table for a program run: The table
receives the status M.
The coordinate values from datum tables are only effective
with absolute coordinate values.
New lines can only be inserted at the end of the table.
