278 Cycles: Coordinate Transformations
11.3 DATUM Shift with Datum Tables (Cycle 7, DIN/ISO: G53)
Editing the datum table in the Programming and
Editing mode of operation
Select the datum table in the Programming and Editing mode of
operation.
U Press the PGM MGT key to call the file manager.
U Display the datum tables: Press the soft keys SELECT
TYPE and SHOW .D.
U Select the desired table or enter a new file name.
U Edit the file. The soft-key row comprises the following
functions for editing:
After you have changed a value in a datum table, you must
save the change with the ENT key. Otherwise the change
might not be included during program run.
Function Soft key
Select beginning of table
Select end of table
Go to previous page
Go to next page
Insert line (only possible at end of table)
Delete line
Confirm the entered line and go to the beginning of
the next line
Add the entered number of lines (datums) to the end
of the table
