HEIDENHAIN iTNC 530 287
11.7 SCALING (Cycle 11, DIN/ISO: G72)
Cycle parameters
U Scaling factor?: Enter the scaling factor SCL. The
TNC multiplies the coordinates and radii by the SCL
factor (as described under “Effect” above). Input
range: 0.000000 to 99.999999
Example: NC blocks
11 CALL LBL 1
12 CYCL DEF 7.0 DATUM SHIFT
13 CYCL DEF 7.1 X+60
14 CYCL DEF 7.2 Y+40
15 CYCL DEF 11.0 SCALING
16 CYCL DEF 11.1 SCL 0.75
17 CALL LBL 1
