298 Cycles: Coordinate Transformations
11.9 WORKING PLANE (Cycle 19, DIN/ISO: G80, Software Option 1)
4 Preparations in the operating mode
Manual Operation
Use the 3D-ROT soft key to set the function TILT WORKING PLANE
to ACTIVE in the Manual Operating mode. For open loop axes, enter
the angular values for the rotary axes into the menu.
If the axes are not controlled, the angular values entered in the menu
must correspond to the actual position(s) of the rotary axis or axes,
respectively. The TNC will otherwise calculate a wrong datum.
5 Datum setting
îš„ Manually by touching the workpiece with the tool in the untilted
coordinate system.
îš„ Controlled with a HEIDENHAIN 3-D touch probe (see the Touch
Probe Cycles User's Manual, chapter 2).
îš„ Automatically with a HEIDENHAIN 3-D touch probe (see the Touch
Probe Cycles User's Manual, chapter 3).
6 Start the part program in the operating mode Program Run, Full
Sequence
7 Manual Operation mode
Use the 3-D ROT soft key to set the TILT WORKING PLANE function
to INACTIVE. Enter an angular value of 0° for each rotary axis in the
menu.
