300 Cycles: Coordinate Transformations

11.10 Programming Examples

18 L Z+250 R0 FMAX M2

Retract in the tool axis, end program

19 LBL 1

Subprogram 1

20 L X+0 Y+0 R0 FMAX

Define milling operation

21 L Z+2 R0 FMAX M3

22 L Z-5 R0 F200

23LX+30RL

24 L IY+10

25 RND R5

26 L IX+20

27 L IX+10 IY-10

28 RND R5

29 L IX-10 IY-10

30 L IX-20

31 L IY+10

32 L X+0 Y+0 R0 F5000

33 L Z+20 R0 FMAX

34 LBL 0

35 END PGM COTRANS MM
