314 Using Touch Probe Cycles
13.1 General Information about Touch Probe Cycles
Defining the touch probe cycle in the Programming and Editing
mode of operation
U The soft-key row shows all available touch probe
functions divided into groups.
U Select the desired probe cycle, for example datum
setting. Cycles for automatic tool measurement are
available only if your machine has been prepared for
them.
U Select a cycle, e.g. datum setting at pocket. The TNC
initiates the programming dialog and asks for all
required input values. At the same time a graphic of
the input parameters is displayed in the right screen
window. The parameter that is asked for in the dialog
prompt is highlighted.
U Enter all parameters requested by the TNC and
conclude each entry with the ENT key.
U The TNC ends the dialog when all required data has
been entered
Example: NC blocks
5 TCH PROBE 410 DATUM INSIDE RECTAN.
Q321=+50 ;CENTER IN 1ST AXIS
Q322=+50 ;CENTER IN 2ND AXIS
Q323=60 ;FIRST SIDE LENGTH
Q324=20 ;2ND SIDE LENGTH
Q261=-5 ;MEASURING HEIGHT
Q320=0 ;SETUP CLEARANCE
Q260=+20 ;CLEARANCE HEIGHT
Q301=0 ;MOVE TO CLEARANCE
Q305=10 ;NO. IN TABLE
Q331=+0 ;DATUM
Q332=+0 ;DATUM
Q303=+1 ;MEAS. VALUE TRANSFER
Q381=1 ;PROBE IN TS AXIS
Q382=+85 ;1ST CO. FOR TS AXIS
Q383=+50 ;2ND CO. FOR TS AXIS
Q384=+0 ;3RD CO. FOR TS AXIS
Q333=+0 ;DATUM
Group of measuring cycles Soft key Page
Cycles for automatic measurement and
compensation of workpiece
misalignment
Page 320
Cycles for automatic workpiece
presetting
Page 342
Cycles for automatic workpiece
inspection
Page 396
Calibration cycles, special cycles Page 446
Cycles for automatic kinematics
measurement
Page 462
Cycles for automatic tool measurement
(enabled by the machine tool builder)
Page 494
