HEIDENHAIN ITNC 530 - CYCLE PROGRAMMING User Manual

398 Touch Probe Cycles: Automatic Workpiece Inspection
16.1 Fundamentals
Example: Measuring log for touch probe cycle 421:
Measuring log for Probing Cycle 421 Hole Measuring
Date: 30-06-2005
Time: 6:55:04
Measuring program: TNC:\GEH35712\CHECK1.H
Nominal values: Center in reference axis: 50.0000
Center in minor axis: 65.0000
Diameter: 12.0000
Given limit values:Maximum dimension for center in reference axis:
50.1000 Minimum limit for center in reference axis: 49.9000
Maximum limit for center in minor axis: 65.1000
Minimum limit for center in minor axis: 64.9000
Maximum dimension for hole: 12.0450
Minimum dimension for hole: 12.0000
Actual values: Center in reference axis: 50.0810
Center in minor axis: 64.9530
Diameter: 12.0259
Deviations: Center in reference axis: 0.0810
Center in minor axis: -0.0470
Diameter: 0.0259
Further measuring results: Measuring height: -5.0000
End of measuring log
