17.8 CALIBRATE TS (Cycle 460, DIN/ISO: G460)
Cycle parameters
U Exact calibration sphere radius Q407: Enter the
exact radius of the calibration sphere used. Input
range 0.0001 to 99.9999
U Setup clearance Q320 (incremental): Additional
distance between measuring point and ball tip. Q320
is added to MP6140. Input range 0 to 99999.9999,
alternatively PREDEF
U Traversing to clearance height Q301: Definition of
how the touch probe is to move between the
measuring points:
0: Move at measuring height between measuring
points
1: Move at clearance height between measuring
points
Alternatively PREDEF
U No. of probe points in plane (4/3) Q423: Specify
whether the TNC should measure the calibration
sphere in the plane with 4 or 3 probing points. 3
probing points increase the measuring speed:
4: Use 4 measuring points (standard setting)
3: Use 3 measuring points
U Reference angle Q380 (absolute): Reference angle
(basic rotation) for measuring the measuring points in
the active workpiece coordinate system. Defining a
reference angle can considerably enlarge the
measuring range of an axis. Input range 0 to 360.0000
U Calibrate length (0/1) Q433: Define whether the
TNC is to calibrate the touch probe length after radius
calibration, as well:
0: Do not calibrate touch probe length
1: Calibrate touch probe length
U Datum for length Q434 (absolute): Coordinate of the
calibration sphere center. The definition is only
required if length calibration is to be carried out. Input
range: -99999.9999 to 99999.9999
Example: NC blocks
5 TCH PROBE 460 CALIBRATE TS
Q407=12.5 ;SPHERE RADIUS
Q320=0 ;SETUP CLEARANCE
Q301=1 ;MOVE TO CLEARANCE
Q423=4 ;NO. OF PROBE POINTS
Q380=+0 ;REFERENCE ANGLE
Q433=0 ;CALIBRATE LENGTH
Q434=-2.5 ;DATUM
