HEIDENHAIN iTNC 530 479
18.4 MEASURE KINEMATICS (Cycle 451, DIN/ISO: G451; Option)
Log function
After running Cycle 451, the TNC creates a measuring log
(TCHPR451.TXT) containing the following information:
îš„ Creation date and time of the log
îš„ Path of the NC program from which the cycle was run
îš„ Mode used (0=Check/1=Optimize position/2=Optimize pose)
îš„ Active kinematic number
îš„ Entered calibration sphere radius
îš„ For each measured rotary axis:
îš„ Starting angle
îš„ End angle
îš„ Angle of incidence
îš„ Number of measuring points
îš„ Dispersion (standard deviation)
îš„ Maximum error
îš„ Angular error
îš„ Ascertained backlash
îš„ Averaged positioning error
îš„ Measuring circle radius
îš„ Compensation values in all axes (preset shift)
îš„ Evaluation of measuring points
îš„ Measurement uncertainty of rotary axes
