Operating mode display 5.4.1
The following displays are possible in the operating mode display of the LCD:
Display
Meaning
ATC150
Pe:x.xxr
Start indicator of the periphery controller program
(during synchronisation with the motor controller)
Heras HMD24
Hold-to-run
operation
Hold-to-run operating mode
Rest status
Hold-to-run
operation
Open
Hold-to-run operation;
Gate opening is active
Hold-to-run
operation
Close
Hold-to-run operation;
Gate closing is active
Heras HMD24
Automatic
mode
Automatic operating mode;
Rest status
Automatic
mode
Open
Automatic mode;
Gate opening is active
Automatic
mode
Close
Automatic mode;
Gate closing is active
Automatic
mode
Immediate
stop
Automatic mode;
Gate is being stopped
Automatic
mode
Close: tt
Automatic mode;
Gate will automatically close in tt seconds
Auto.Closing-
run ON
---------?
The control system is waiting for the first movement
command after switching on or reset
