EN – Translation of the original user manual - 2.0 | 2019
41
 Switch on the power supply of the motor drive.
 Check that the keys work.
Setting up the partOPEN function (pedestrian passage) 6.4.6
A pushbutton or switching contact (normally open contact) is connected to input
In4 of variants 1 and 2 for setting up a partOPEN function (pedestrian passage).
 Switch off the power supply to the motor drive.
 Connect the keys to the 24V power supply.
 Connect the PARTLY OPEN key to input terminal IN 4 (normally open
contact).
 Switch on the power supply of the motor drive.
 Check that the keys work.
The opening width of the gate from the CLOSED position to the partOPEN position
depends on the preset motor runtime for this path. This preset runtime can be
changed in the menu as follows:
 Menu: “Settings”, “Set timer”, “Runtime to partOPEN”: select lower or
higher value (increase or decrease opening width).
 Exit menu.
 Move gate from the CLOSED position to the partOPEN position and check
opening width.
Control element switchover impulse pushbutton (toggle) 6.4.7
At the input “In3” (variants 1 and 3) a pushbutton can be connected which
generates the movement commands OPEN, STOP, CLOSE, STOP by means of a
switchover impulse (toggle function). Every time a key is operated, either a new
motor operation is started or an ongoing operation is interrupted by a stop
command. The new movement direction is always in the opposite direction to the
last one. This function is only supported in automatic mode.
 Switch off the power supply to the motor drive.
 Connect the keys to the 24V power supply.
 Connect the TOGGLE key to input terminal IN3 (normally open contact).
 Switch on the power supply of the motor drive.
 Check that the keys work.
