 Exit menu
 Programming and teaching the JCM system in accordance with the JCM user
manuals for the RB3 system.
 Check that the accompanying strips are correctly connected by checking the
“Sensor Display” screen and the response of the gate for the corresponding
direction of movement in “Automatic mode”.
7.3 OPERATING FUNCTIONS AT THE INPUTS IN3 AND IN4
In the “Settings” menu, three different combinations can be selected for the two
command inputs In3 and In4 by selecting the sub-menu “Input: In3/4”. Variants
1 to 3 are available, which are listed in the following three tables.
Variant 1
Terminal
no.
Designatio
n
Input function
3
In8
Hold-to-run OPEN pushbutton (e.g. key switch on
the gate)
4
In7
Hold-to-run CLOSE pushbutton (e.g. key switch at
the gate)
5
In6
STOP pushbutton (normally closed contact)
6
In5
OPEN impulse
7
In4
PartOPEN impulse (pedestrian passage)
8
In3
TOGGLE switchover impulse
(OPEN/STOP/CLOSE/STOP)
9
In2
Limit switch for OPEN position (normally closed
contact)
10
In1
Limit switch for CLOSED position (normally closed
contact)
By default, the partOPEN command function is found at input terminal In4 in
variant 1. The input In3 is used for the function ‘toggle switchover impulse’.
For the two inputs “In4” and “In3”, marked in colour, the following alternative
input functions can be selected under the “Settings” menu item:
