EN – Translation of the original user manual - 2.0 | 2019
Sensor display 5.4.2
Using the display, it is also possible to obtain detailed information about the
configured sensors. Pressing the rotary and selection switch lists the current
status of the preset sensors. Rotating the switch displays the individual sensors
one after another.
The first line always shows the sensor from the parameter list.
The second line shows the current status of the sensor. A “1” represents an
active sensor; a “0” represents an inactive sensor. These displays are
continuously updated and make fault finding easy. They are overwritten by the
operating mode display 60 seconds after the most recent operation of the rotary
switch.
Sensors that have not been installed (specified by parameters in the program) are
not displayed.
Rotating the selection switch to the left reaches the first
entry in the sensor table
Limit switch
OPEN
Value: 2 => x
Current value of the limit switch for the OPEN direction of
the gate
Limit switch
CLOSE
Value: 1 => x
Current value of the limit switch for the CLOSE direction of
the gate
Fixed.StripOPE
N
Value: 1 => x
Status of the fixed safety contact strip for the OPEN direction
of the gate
Fixed.StripCLO
SE
Value: 1 => x
Status of the fixed safety contact strip for the CLOSE
direction of the gate
Acc.StripOPEN
Value: 1 => x
Status of the accompanying safety contact strip for the OPEN
direction of the gate
Acc.StripCLOS
E
Value: 1 => x
Status of the accompanying safety contact strip for the
CLOSE direction of the gate
Light barrier
Value: 1 => x
Current status of the light barrier
Max. motor
current
xx/yy A
Left-hand value (xx): maximum current during the last
motor movement
Right-hand value (yy): maximum current since last resetting
of the values
