TECHNICAL DATA 13
13.1 SLIDING GATE DESCRIPTION
Gate leaf
Delta
Length [m]
5.15 …
12.5
Height [m]
1.00 … 2.5
Max. weight [kg]
340
Construction
cantilever
13.2 DRIVE DESCRIPTION
HMD24 DC
Electrical values
Power supply
1 phase 230 V
AC
/ N/PE 50/60 Hz
or 24 V
DC
(e.g. battery)
Fuse protection (on site)
when operated on power
network
max. 10 A
External power supply for
external 24 V devices
24 V
DC
stabilised (±5 %) max. 500 mA
(protected with self-resetting semiconductor
fuse)
Control inputs
24 V
DC
/typical 4 mA
< 12 V: inactive -> logically 0
> 18 V: active -> logically 1
(internally electrically isolated)
Relay outputs
1
max. 250 V
AC
/1 A or 250 W
maximum el. motor
performance
500 W
Mechanical values
Housing material
ABS plastic
1
If inductive loads are switched (e.g. further relays or brakes), these must be equipped with a
free-wheeling diode as an interference suppression measure.
