FAULTS 8
8.1 DEFECTIVE PHOTOCELL OR SAFETY EDGE
If a photocell or safety device is defective, the gate can only be opened and closed
using the hold-to-run switch. In this case, consult a qualified technician.
See chapter “SERVICE / MAINTENANCE”
8.2 PARAMETERS REFERENCE/ERROR NUMBERS
The possible entries in the log system described above for events and/or errors
are listed in the table below:
Reference/
Error no.
Text
Meaning
25
Fixed.StripOPEN
Fixed safety contact strip OPEN was activated
(a ‘0’ is stored immediately after the text if the
motor was not active)
26
Fixed.StripCLOS
E
Fixed safety contact strip CLOSE was activated
(a ‘0’ is stored immediately after the text if the
motor was not active)
27
Acc.StripOPEN
Accompanying safety contact strip OPEN was
activated
(a ‘0’ is stored immediately after the text if the
motor was not active)
28
Acc.StripCLOSE
Accompanying safety contact strip CLOSE was
activated (a ‘0’ is stored immediately after the
text if the motor was not active)
40
Light barrier
The light barrier was activated during the CLOSE
movement
86
Number of
reversals
The maximum number of reversals for a
movement direction (without reaching the limit
position) was reached
130
Scstrip
OPENtsterr
Error in test result for the fixed safety contact
strip OPEN was detected
131
Scstrip CLOSE
tsterr
Error in test result for the fixed safety contact
strip CLOSE was detected
