c) Seat the drive by pressing the lever into the drive carrier. This will allow the drive to make the connection
with the connector on the drive board without causing damage.
Figure 149: Drive Assembly Lever
17. Uninstall the Compute Canister from the enclosure.
a) From the rear of the enclosure, determine which of the two Compute Canisters is in need of
replacement.
b) Unlatch the Compute Canister by pulling both of the handles out of the chassis.
Figure 150: Unlatching the Compute Canister
100
3 Part Replacement
User Guide 3.11 Chassis Replacement
