c) Remove the Compute Canister by grasping the edges of the canister and pulling it clear of the
enclosure.
Figure 151: Uninstalling the Compute Canister
18. Repeat the previous step to uninstall the remaining Compute Canister.
19. Locate the Compute Canister slots on the rear of the new enclosure chassis.
20. Install the Compute Canister into the enclosure.
a) From the rear of the enclosure, line up the Compute canister with the empty canister slot. Ensure that
the Compute Canister is oriented correctly.
Note: The top Compute Canister is installed with the top cover facing toward the bottom of the
enclosure. The bottom Compute Canister is installed with the top cover facing the top of the
enclosure.
101
3 Part Replacement
User Guide 3.11 Chassis Replacement
