a) Line up the enclosure with the rack mounted rails and slide it in until the enclosure is seated against
the rack mounted rails.
Figure 154: Installing the Enclosure
b) Locate the thumbscrews on either side of the enclosure.
c) Press and tighten the thumbscrews by turning them clockwise until snug.
Figure 155: Tightening the Thumbscrews
103
3 Part Replacement
User Guide 3.11 Chassis Replacement
