HIKVISION DS-7200HGHI-K1 Series User Manual

Digital Video Recorder User Manual
141
Step 3 You can also click to overlay all POS items to the first 8 channels in order. And the
is used to clear all POS overlay settings.
Step 4 Click the Apply button to save the settings.
9.3 Configuring POS Alarm
Purpose
Set the POS alarm parameters to trigger certain channels to start recording, or trigger full screen
monitoring, audio warning, notifying the surveillance center, sending email and so on.
Step 1 Go to Menu > Configuration > POS > POS Settings.
Step 2 Follow the steps in Chapter 9.1-9.2 to configure the POS settings.
Step 3 Click to enter the alarm settings interface.
Figure 9-15 Set Trigger Cameras of POS
Step 4 Click Trigger Channel tab and select one or more channels to record or become full-screen
monitoring when POS alarm is triggered.
Step 5 Set arming schedule of the channel.
Select Arming Schedule tab to set the channel’s arming schedule.
Choose one day of a week and up to eight time periods can be set within each day. Or you
can click the Copy button to copy the time period settings to other day(s).
Time periods shall not be repeated or overlapped.

HIKVISION DS-7200HGHI-K1 Series Specifications

General

Audio Output	1 channel
Two-Way Audio	Yes
Frame Rate	Up to 30fps
Audio Bitrate	64Kbps
Dual Stream	Yes
Capacity	Up to 10TB per HDD
Working Humidity	10% to 90%
Video Compression	H.264+, H.264
Analog Video Input	16 channels
HDTVI Input	16 channels
AHD Input	16 channels
HDCVI Input	16 channels
CVBS Input	16 channels
IP Video Input	Up to 8 channels
HDMI Output	1 channel
VGA Output	1 channel
Audio Input	4 channels
Video Bitrate	32 Kbps to 6 Mbps
Audio Compression	G.711
Stream Type	Video & Audio
Synchronous Playback	4/8/16 channels
Network Protocols	TCP/IP, DHCP, DNS, DDNS, PPPoE, NTP, UPnP
Remote Connections	Up to 128
Network Interface	1 x RJ45
SATA	2 SATA ports
USB Interface	2 x USB 2.0
Power Supply	12 VDC
Working Temperature	-10°C to +55°C (14°F to 131°F)
Weight	2.5kg
