HIKVISION DS-7200HGHI-K1 Series

Network Video Recorder User Manual
27
No.
Name
Function Description
Stops/starts auto switch in Auto-switch mode.
5
POWER
Power on/off switch.
6
JOG SHUTTLE Control
Moves the active selection up and down in a menu.
Cycles through different channels in live view mode.
Jumps 30s forward/backward in video files in the
playback mode.
Controls the movement of the PTZ camera in PTZ
control mode.
Moves the active selection up and down in a menu.
7
USB Interface
Universal Serial Bus (USB) ports for additional devices
such as USB mouse and USB Hard Disk Drive (HDD).
8
IR Receiver
Receiver for IR remote control.
DS-8100HQHI/HUHI/HTHI-K8, DS-
9000HUHI/HTHI-K8 and iDS-9016HUHI-K8/16S
Front Panel of DS-8100HQHI/HUHI/HTHI-K8
