Network Video Recorder User Manual
38
Rear Panel
The rear panel varies according to different models. Please refer to the actual product. The
following figures are for reference only.
DS-7100HQHI-K1, DS-7200HUHI-K (/P), iDS-
7200HUHI-K/4S, DS-7200HTHI-K, DS-7200HQHI-K(/P),
and iDS-7200HQHI-K/S
Rear Panel of DS-7100HQHI-K1
Rear Panel of DS-7200HUHI-K and iDS-7200HUHI-K/4S
Rear Panel of DS-7200HUHI-K/P
