HIKVISION DS-7600NI-SE/P Series - Product Application Diagram

DS-7600 Series NVR User’s Manual
11
9
USB Interface
Universal Serial Bus (USB) ports for additional devices
such as USB mouse and USB Hard Disk Drive (HDD).
10
PoE Interface
Network interface for the cameras and to provide power
over Ethernet.
Product Application Diagram
Figure 3 Product Application Diagram
Note:
DS-7600NI-SE/P can only connect network cameras.
