DS-7600 Series NVR User’s Manual
71
8. Select the Apply button to save the motion detection settings and select OK to return to the
previous menu. Selecting the Cancel button without clicking Apply or OK will quit out of the
menu without saving settings.
Configuring Alarm Inputs
If the camera supports alarm input, certain actions can be performed when an alarm input is triggered. If
no connected camera supports alarm input, an attention message will pop up as shown below.
Figure 68 Alarm Attention Message
To setup trigger actions:
1. Enter the Trigger menu, shown in Figure 69 by going to Menu > Recording Configuration >
Trigger.
Figure 69 Trigger Settings Menu
2. Select the Alarm Input tab.
3. Select the Alarm Input No. in the dropdown list.
4. Edit the Alarm Name.
5. Select the trigger Type for the external alarm input device. N.O means Normal Open. N.C means
Normal Close. These two types can be selected.
6. Check the Enable Alarm Input checkbox to enable the selected alarm input. Uncheck the
checkbox to disable alarm input.
7. Click the Set button to pop up the Settings menu, as shown in Figure 70.
