DS-7600 Series NVR User’s Manual
77
Configuring Cameras
Adding IP Cameras
The DS-7600NI-SE/P series NVR provides PoE interfaces which can connect to IP cameras directly. The
PoE interface supports Plug-and-Play function. You can also connect to the online IP camera manually.
Before configuring IP cameras, please ensure the network settings for your NVR is properly setup.
To manage IP cameras:
Plug-and-Play
1. Enter the Network menu by going to Menu > System Configuration > Network and check the
Internal NIC IPv4 is configured properly.
2. Connect the cameras via PoE interface.
3. Enter the Cameras menu by going to Menu > Cameras Setup > Cameras, as shown in Figure 75.
Figure 75 Cameras Configuration Menu
4. The cameras connect via PoE interface are listed with internal NIC IP address.
Note:
The Plug-and-Play camera cannot be deleted and edit in this interface.
Manual
1. Enter the Cameras menu as shown in Figure 75.
2. Click the Search button to automatically detect connected IP cameras on the network.
3. Left-click the detected cameras. The basic information of the selected camera will display on the
left side of the interface.
4. Click near the IP address to modify the camera’s IP address, subnet mask and port. Input the
password and click Apply to confirm the settings.
5. You can also click Protocol to pop up a Protocol Management windows, as shown in Figure 76,
to edit the protocol parameters.
