DS-7600 Series NVR User’s Manual
28
3. Control the PTZ by using PTZ control buttons. Pan and tilt PTZ by clicking on the directional
buttons. Zoom in and out using the Zoom In/Out buttons and recall presets, patrols and patterns
by clicking the corresponding icons.
Below is the description of the PTZ control icons:
Direction buttons and the auto-cycle button
Zoom+/Zoom-
Focus+/Focus-
Iris+/Iris-
The speed of the PTZ movement
Light On/Off
Wiper On/Off
3D-Zoom
Image Centralization
Menu
4. Click to return to the Live Feed mode.
Note:
PTZ parameters for the camera must be set correctly before the PTZ can be controlled.
Digital Zoom Mode:
Enable digital zoom on the selected channel. Once enabled, the regular feed will be shown in the lower
right corner while the zoomed in view will be shown on the full screen. The zoomed in region may be
changed by moving the red rectangle in the regular feed window, as shown in the Figure 18. Right click
to back to the Live Feed mode.
