HIKVISION DS-KV8213-WME1 - Two-Button Villa Door Station

DS-KV8x13-WME1 Video Intercom Villa Door Station User Manual
UM DS-KV8x13-WME1 Villa Door Station 062321NA 11
1.2. Two-Button Villa Door Station
Figure 2, Two-Button Villa Door Station Appearance
Table 1-2 Description
No.
Description
1
Microphone
2
Indicator: Unlock (Green)/Call (Orange)/Communicate (White)
3
Camera
4
Loudspeaker
5
Button
6
Card Reading Area
7
IR Light
8
MicroSD Card Slot (Reserved) and Debugging Port
9
LAN
10
Terminals
