DS-KV8x13-WME1 Video Intercom Villa Door Station User Manual
UM DS-KV8x13-WME1 Villa Door Station 062321NA 26
Figure 21, Port Settings
Set the device ports.
HTTP Port: The default port number is 80, and it can be changed to any port no. that is not
occupied.
HTTPS Port: The default port number is 443, and it can be changed to any port no. that is not
occupied.
RTSP Port: The default port number is 554.
Server Port: The default server port number is 8000, and it can be changed to any port no.
ranging from 2000 to 65535.
Click Save to enable the settings.
SIP Setting
Steps
Click Network → Basic Settings → SIP to enter the settings page.
Figure 22, SIP Settings
Check Enable VOIP Gateway.
Configure the SIP parameters.
Click Save to enable the settings.

HIKVISION DS-KV8213-WME1 Specifications

General

Color	-
Relay inputs	1
Speakerphone	Yes
Number of buttons	2 buttons
Connectivity technology	Wired
Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	480p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Voice codecs	G.711u
LED type	IR
Night vision distance	3 m
Outdoor unit power type	DC
Power consumption (typical)	10 W
Display diagonal	- \
Operating temperature (T-T)	-40 - 53 °C
Operating relative humidity (H-H)	10 - 95 %
IK code	IK08
Proper use	Outdoor
Product color	Gray
International Protection (IP) code	IP65
Package depth	120 mm
Package width	140 mm
Package height	220 mm
Indoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RSTP
Operating system installed	Linux

Weight and Dimensions

Weight	385 g
