DS-KV8x13-WME1 Video Intercom Villa Door Station User Manual
UM DS-KV8x13-WME1 Villa Door Station 062321NA 38
Figure 37, Elevator Control
Check to enable elevator control function.
Select an Elevator No., and select an elevator controller type for the elevator.
Set the Negative Floor.
Set the Interface Type as RS-485 or Network Interface, and enable the elevator control.
RS-485: Make sure you connected the door station to the elevator controller with an RS-485 cable.
Network Interface: Enter the elevator controller’s IP address, port no., user name, and password.
Click Save to enable the settings.
NOTE: Up to four elevator controllers can be connected to one door station.
Up to 10 negative floors can be added.
Make sure the elevator controller interface types connected to the same door
station are consistent.

HIKVISION DS-KV8213-WME1 Specifications

General

Color	-
Relay inputs	1
Speakerphone	Yes
Number of buttons	2 buttons
Connectivity technology	Wired
Megapixel	2 MP
Maximum frame rate	30 fps
Supported video modes	480p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Voice codecs	G.711u
LED type	IR
Night vision distance	3 m
Outdoor unit power type	DC
Power consumption (typical)	10 W
Display diagonal	- \
Operating temperature (T-T)	-40 - 53 °C
Operating relative humidity (H-H)	10 - 95 %
IK code	IK08
Proper use	Outdoor
Product color	Gray
International Protection (IP) code	IP65
Package depth	120 mm
Package width	140 mm
Package height	220 mm
Indoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RSTP
Operating system installed	Linux

Weight and Dimensions

Weight	385 g
