Hioki 3455 - Page 39

2.1 Supplying Power
1
2
3
4
5
6
7
8
9
10
11
付録
索引
33
3. Place six LR6 alkaline batteries into the
battery compartment. (Replace all six at
the same time)
4. Turn the battery selector switch to LR6.
When the power is turned on, “Lr6” appears
on the top left of the screen.
 See 2.2 "Turning Power On and Off" (page 44).
5. Replace the battery cover and tighten
the set screw.
To LR6
