8.4 Analyzing Transient Waveforms

128

You can check all waveform data by scrolling the waveform horizontally.

Scrolling the transient waveform

[SCROLL]

Scroll the

waveform

Scroll bar

Display scope

All measurement data

The display scope on the scroll bar

(shown in white) illustrates which

range of all measurement data is

being shown on the screen.

Display scope

Return to

event list
