13.3 Measurement Specifications
184
Measurement accuracy with a fundamental wave of 50/60 Hz
Harmonic input Measurement accuracy Notes
Voltage At least 1% of
nominal
voltage
Order 0 : 0.3% rdg.0.08%f.s.
Order 1+ : 5.00% rdg.
Specified with a nominal
voltage of at least 100 V.
<1% of nomi-
nal voltage
Order 0 : 0.3% rdg.0.08%f.s.
Order 1+ : 0.05% of nominal voltage
Specified with a nominal
voltage of at least 100 V.
Current Order 0 : 0.5% rdg.0.5%f.s.
Orders 1 to 20
th
: 0.5% rdg.0.2%f.s.
Orders 21 to 50
th
: 1.0% rdg.0.3%f.s.
Add clamp sensor accuracy.
Power Order 0 : 0.5% rdg.0.5%f.s.
1 to 20
th
: 0.5% rdg.0.2%f.s.
21 to 30
th
: 1.0% rdg.0.3%f.s.
Orders 31 to 40
th
: 2.0% rdg.0.3%f.s.
Orders 41 to 50
th
: 3.0% rdg.0.3%f.s.
Add clamp sensor accuracy.
Measurement accuracy with a fundamental wave of 400 Hz
Harmonic input Measurement accuracy Notes
Voltage Order 0 : 0.5% rdg.0.08%f.s.
Orders 1 to 2
th
: 0.5% rdg.0.20%f.s.
Orders 3 to 6
th
: 1.0% rdg.0.30%f.s.
Orders 7 to 10
th
: 5.0% rdg.0.30%f.s.
Current Order 0 : 0.5% rdg.0.5%f.s.
1 to 2
th
: 0.5% rdg.0.2%f.s.
3 to 6
th
: 1.0% rdg.0.3%f.s.
7 to 10
th
: 5.0% rdg.0.3%f.s.
Add clamp sensor accuracy.
Power Order 0 : 0.5% rdg.0.5%f.s
1 to 2
th
: 0.5% rdg.0.2%f.s.
3 to 6
th
: 1.0% rdg.0.3%f.s.
7 to 10
th
: 7.0% rdg.0.3%f.s.
Add clamp sensor accuracy.
Inter-harmonic voltage and inter-harmonic current (Uiharm, Iiharm)
Measurement method Uses IEC61000-4-7:2002.
Anti-aliasing low-pass filter causes attenuation of frequencies other than measurement target of at
least 50 dB.
After harmonic analysis, harmonic voltage and current are summed and displayed as inter-har-
monic contents with the harmonic contents according to harmonic order
Measurement accuracy is specified for input that is 10% to 200% of IEC61000-2-4 Class 3.
Analysis window width 10 cycles (50 Hz) or 12 cycles (60 Hz)
No. of window points Rectangular, 4,096 points
Displayed item 0.5 to 49.5 orders (of 42.5- to 70-Hz fundamental waveform)
Select either RMS or content percentage (When using content percentage, zero suppression
causes all orders to be given as 0% when the RMS value is 0.)
Measurement range, resolution Inter-harmonic voltage: U1 to U4, 600.00 V
Inter-harmonic current: I1 to I4, Varies with current range (see input specifications).
Measurement accuracy Inter-harmonic voltage (Specified with a nominal voltage of at least 100 V.)
At least 1% of harmonic input nominal voltage:: 5.00% rdg.
<1% of harmonic input nominal voltage: 0.05% of nominal voltage
Inter-harmonic current: Unspecified
Event threshold N/A
Constraints Not displayed for 400 Hz measurement.
