13.6 Measurement and Analysis Function Specifications
193
10
13
Chapter 13 Specifications
[EVENT] screen
Display refresh rate Every 1 min (V10 overall maximum value), every 1 hr (others)
Display selection CH1 to CH3 (varies with connection)
Constraints No display for 400 Hz measurement
V10 flicker list display (when flicker is set to V10)
IEC flicker graph display (when flicker is set to IEC [Pst, Plt])
Displayed content Time series graph of Pst and Plt values
Constraints No display for 400 Hz measurement
IEC flicker list display (when flicker is set to IEC [Pst, Plt])
Displayed content Pst and Plt values
Display refresh rate Each time Pst is updated
Constraints No display for 400 Hz measurement
Event list display
Display format • Event list display
• Event details display (detailed information for event selected on event list)
• Waveform display (waveform for event selected on event list; either voltage or current screen as
set with [VIEW] screen's [VOLT/CURR] display setting)
Event list display order Order of occurrence
Event jump function Allows details for specified event to be analyzed on [VIEW] screen.
