13.6 Measurement and Analysis Function Specifications
192
[TIME PLOT] screen
Trend graph display
Displayed screens 1-screen/2-screen/Energy
Displayed content Time series graph of maximum, minimum, and average values for 1 item on 1-screen display or 2
items on 2-screen display
Select from Freq, Freq10s, Upk+, Upk-, Ipk+, Ipk-, Urms, UrmsAVG, Udc, Irms, IrmsAVG, Idc, P, S,
Q, PF, DPF, Uunb0, Uunb, Iunb0, Iunb, UharmH, IharmH, Uthd-F, Uthd-R, Ithd-F, Ithd-R, and KF.
"Integration" refers to a time series graph of 1 integrated item.
Display update rate during
measurement
Every TIMEPLOT interval
Detailed trend graph display (interval)
Displayed screens Time series graph of maximum and minimum values for fluctuation data
Displayed content Select any 1 of Urms1/2, Irms1/2, S(t), and frequency cycle.
(S(t) cannot be selected during 400 Hz measurement.)
Display update rate during
measurement
Every TIMEPLOT interval
Fluctuation data display (detailed trend graph at event occurrence)
Displayed screens Time series graph of fluctuation data at event occurrence (from 0.5 s before to 29.5 s after event
occurrence for 50/60 Hz measurement; from 0.125 s before to 7.375 s after event occurrence for
400 Hz measurement)
Displayed content Either Urms1/2 or Irms1/2 (inrush current)
Display update rate during
measurement
Each time a displayed event occurs (display is overwritten)
Harmonic trend graph display
Displayed screens 1-screen display
Displayed content Time series graph of maximum, minimum, and average values for up to 6 items
Display update rate during
measurement
Every TIMEPLOT interval
Inter-harmonics trend graph display
Displayed screens 1-screen display
Displayed content Time series graph of maximum, minimum, and average values for up to 6 items
Display update rate during
measurement
Every TIMEPLOT interval
V10 flicker graph display (when flicker is set to V10)
Displayed content Time series graph of V10 (instantaneous value)
(simultaneous display for all measurement channels)
Constraints No display for 400 Hz measurement
V10 flicker list display (when flicker is set to V10)
Displayed content V10 1-hour average value, V10 1-hour maximum value, V10 1-hour fourth-largest value, V10
overall maximum value
