6.2 Loading Measurement Conditions (Panel Load Function)
121
6
Loads the measurement settings saved by the Panel Save function.
By default, loading a panel causes zero-adjustment values to be loaded. If you do not wish
to load zero-adjustment values, see "Preventing Loading of Zero-adjustment Val-
ues"(p.122).
6.2 Loading Measurement Conditions
(Panel Load Function)
1
Open the Panel List Screen.
2
Select a panel number.
3
Verify that the confirmation message is shown and return to the Measurement
screen.
The Panel List Screen
appears.
2
Selection
1
Load the panel.
(You can also load the
panel with the
key.)
Data saved for selected panel
Load the panel and switch
to the Measurement screen
(you can also do this with
the key).
Cancel the operation and
return to the previous
screen. (you can also do
this with the key)
The name of the loaded
panel will be displayed on
the Measurement screen.
To Next Page
