2.3 Connecting Z2001 Temperature Sensor or Thermometer with Analog Output (When using
40
After turning on the instrument, check whether the temperature measurement settings are
correct. Change if necessary.
1
Open the Settings Screen.
2
Open the System Setting Screen.
3
Select TEMP INPUT and press (ANLG-V).
The Settings screen
appears.
Switch the function menu
to P.2/3.
1
2
Move the cursor to the [SYS]
tab with the left and right cur-
sor keys.
To Next Page
