Hioki RM3545-02 - Measurement

2.3 Connecting Z2001 Temperature Sensor or Thermometer with Analog Output (When using
41
2
The displayed value is calculated by the following expression.
4
Set two reference voltages and the corresponding reference temperatures.
Set reference voltages V
1
and V
2
and reference temperatures T
1
and T
2
by following
Steps
1 through 3 for each.
5
Return to the Measurement screen.
Move the cursor to the setting you
wish to configure. Make the value
editable with the key.
2
Move the cursor to the digit you
wish to set with the left and right
cursor keys. Change the value
with the up and down cursor keys.
Change
values.
1
Move among
digits.
3
Accept
( Cancel)
Setting range
reference voltage (V
1
, V
2
): 00.00 to 02.00 V (default V
1
: 0 V, V
2
: 1 V)
reference temperature (T
1
, T
2
): -99.9 to 999.9°C (default T
1
: 0°C, T
2
: 100°C)
Return to the
Measurement screen.
V1 V20
T1
T2
アナログ入力電圧
温度
T
2
− T
1
V
2
− V
1
⋅ (Input Voltage) +
T
1
V
2
− T
2
V
1
V
2
− V
1
T
2
T
1
V
1
V
2
Temperature
Analog Input Voltage
