Hioki RM3545-02 - Page 93

4.9 Setting Pre-Measurement Delay
85
4
• The preset value is set assuming about 10 mH of inductance and varies with each mea-
surement range.
• When using the EXT trigger source, the measurement current will not be stopped for
measurement ranges of 10 k and greater (continuous application).
Contact
Detected
voltage
Measurement
processing
Separation
Measurement
Delay Timing Chart
Probe Contact
Condition
Measurement
Current
