Hirschmann GRS103 Series User Manual

Installation GRS103
Release 01 03/2022
45
6.5.3 Mounting on a vertical flat surface
Install the device in line with the criteria listed in “Installing the device” on
page 42.
Perform the following work steps:
 Remove the screws on the pre-installed mounting brackets.
 Move the 2 pre-installed mounting brackets on the front side into the
position shown in figure 20.
Figure 21: Mounting vertically on a flat surface: Optional mounting on a vertical flat
surface.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 62368-1 if you install
the device vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
