Hirschmann GRS103 Series User Manual

68
Installation GRS103
Release
01
03/2022
14 Immunity
Immunity Standard applications
IEC 60068-2-6, test Fc Vibration 5 Hz ... 8.4 Hz with 3.5 mm (0.14 in) amplitude
8.4 Hz ... 200 Hz with 1 g
IEC 60068-2-27, test Ea Shock 15 g at 11 ms
EMC interference immunity Standard applications
a
a. According to EN 61000-6-2.
Electrostatic discharge
EN 61000-4-2 Contact discharge ±4 kV
EN 61000-4-2 Air discharge ±8 kV
Electromagnetic field
EN 61000-4-3 80 MHz ... 2700 MHz max. 10 V/m
EN 61000-4-3 2.7 GHz ... 6.0 GHz max. 10 V/m, 80 % AM
Fast transients (burst)
EN 61000-4-4 Supply voltage connection ±4 kV
EN 61000-4-4 Data line ±2 kV
Voltage surges - AC supply connection
EN 61000-4-5 line/ground ±2 kV
EN 61000-4-5 line/line ±1 kV
Voltage surges - data line
EN 61000-4-5 line/ground ±1 kV
Conducted immunity
EN 61000-4-6 10 kHz ... 150 kHz 3 V
EN 61000-4-6 150 kHz ... 80 MHz 10 V
Table 21: EMC and immunity: EMC interference immunity
