Hirschmann GRS103 Series User Manual

Installation GRS103
Release 01 03/2022
59
11 Disassembly
Perform the following work steps:
 “Removing an SFP transceiver (optional)”
 “Removing a media module”
 “Removing the device”
11.1 Removing an SFP transceiver (optional)
Figure 28: De-installing SFP transceivers: De-installation sequence
Perform the following work steps:
 Open the locking mechanism of the SFP transceiver (1).
 Pull the SFP transceiver out of the slot via the open locking
mechanism (2).
 Close the SFP transceiver with the protection cap (3).
11.2 Removing a media module
WARNING
FIRE HAZARD
Disconnect the PoE voltage supply before removing the M1-8TP-RJ45 PoE
media module.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
