15.3 Bidirectional Fast Ethernet SFP transceiver
Product code Mode
a
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O
line length
b
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber
attenuation
BLP/Dispersion
SFP-FAST-BA
MM/LC EEC
MM 1310 nm 1550 nm 50/125 µm
62.5/125 µm
0 dB ... 16 dB 0 km ... 2 km
(0 mi ... 1.24 mi)
1.0 dB/km 800 MHz×km
500 MHz×km
SFP-FAST-BB
MM/LC EEC
MM 1550 nm 1310 nm 50/125 µm
62.5/125 µm
0 dB ... 16 dB 0 km ... 2 km
(0 mi ... 1.24 mi)
1.0 dB/km 800 MHz×km
500 MHz×km
SFP-FAST-BA
SM/LC EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 18 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-FAST-BB
SM/LC EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 18 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
0.25 dB/km 19 ps/(nm×km)
SFP-FAST-BA
SM+/LC EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 29 dB 0 km ... 60 km
(0 mi ... 37.29 mi)
0.4 dB/km 3.5 ps/(nm×km)
SFP-FAST-BB
SM+/LC EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 29 dB 0 km ... 60 km
(0 mi ... 37.29 mi)
0.25 dB/km 19 ps/(nm×km)
Table 24: F/O port (bidirectional Fast Ethernet SFP transceiver)
